Excellent result thanks to close, partnership-based cooperation

Large engines of the MTU brand drive vehicles, construction machinery and generators for decentralised energy supply. They often have to prove their reliability for decades. The precision requirements for the components used are correspondingly high. When machining a mounting surface within an exhaust gas component, the accuracy requirements were hampered by accessibility. Rolls-Royce’s division Power Systems, which includes MTU, relies on a customized milling cutter with ISO indexable inserts from MAPAL for this difficult task.

A large engine from MTU is shown against a white background.
  • A large engine from MTU is shown against a white background.
  • Thomas Jungbeck discusses the tool with MTU technicians Hans Schreiner, Waldemar Schmidt and Stefan Wohnhas.
  • Against a white background, an exhaust duct housing made of grey cast iron is shown.
  • View inside the exhaust gas duct housing on the mounting surface to be machined.
  • Someone inserts the tool into an inlet opening on the housing opposite the mounting surface.
  • A frontal view of the special face milling cutter. The four indexable inserts are arranged asymmetrically.
  • View through a large opening into the part. The milling cutter is retracted into the part and at its point of action.
  • The face milling cutter when entering the workpiece via the inlet opening.

Process reliability and very high flatness with customer-specific ISO face milling cutters from MAPAL

In Friedrichshafen, the Rolls-Royce subsidiary MTU Friedrichshafen develops and produces diesel and gas engines for ships, heavy land and rail vehicles, industrial applications and decentralised power supplies. The product range includes series with 8 to 20 cylinders and an output of 800 to 10,000 kW. They are the core of the company’s drive and energy systems. As soon as you arrive in Friedrichshafen by train or ferry from Lake Constance, it is very likely that an MTU product provides the necessary propulsion.

​​​​​​​All application-related differences – engines for large ships have different requirements than those for construction machinery or even emergency power generators –have one thing in common: The drive units must be
  • powerful
  • energy-efficient
  • environmentally friendly
  • ​​​​​​​yet reliable and
  • durable.
The reliable fulfilment of these requirements makes Power Systems a preferred partner for its customers. The MTU Friedrichshafen subsidiary determines not only the goals of the development engineers, but also the precision requirements in manufacturing. This starts in Friedrichshafen with the machining of cast parts and extends to the delivery of the finished engines and complete systems.

Flatness as a quality factor

An example from an exhaust system shows the influence that high precision machining has on the durability and low maintenance of MTU’s large engines. The exhaust gases from each pair of cylinders are removed by means of exhaust gas guide elements made of cast iron with GJL-250 lamellar graphite, which are arranged in modular rows depending on the size of the engine. Inside, moulded parts made of heat-resistant sheet metal absorb the exhaust gases from the engine and transport them to the turbochargers.

These sheet metal parts are fastened to the inside of the cast elements with two screws each. The mounting surface must feature outstanding surface flatness because unevenness provides scope for the sheet metal parts to move. Due to the constant vibrations in piston engines, this could lead to problems over time and in extreme cases even to shearing of a fastening screw.

Area with restricted accessibility

“While we can place the two screw holes from the outside, the mounting surface with both bores can only be machined through the opposite rectangular inlet opening,” says Stefan Wohnhas, the Production Engineer responsible for tool technology at MTU Friedrichshafen, describing the most important machining challenge. “The inlet opening is more than 10 mm narrower than the surface to be machined and is almost 300 mm away.”

​​​​​​​For some time now, the Friedrichshafen company has been using a counterboring tool with adjustable indexable inserts and a working diameter of 51 mm for pre-machining. Due to the small and distant entry opening, the shank of the special tool, which is over 400 mm long, is cranked. Over a length of 325 mm it has a diameter of only 24 mm.

If there was only a single countersink, the finish would also be of sufficient quality with this tool. The counterboring tool centres itself in the first bolt bore and machines the first half of the mounting surface. However, as the tool centres in the other of the two bolt bores for machining the second half of the mounting surface, the indexable inserts pass over a position that has already been machined. This leads to an uneven cutting pressure. “So we were unable to comply with the required 70 μm flatness,” reports Hans Schreiner, who can draw on 40 years of experience at MTU Friedrichshafen and is responsible for tool planning and procurement for large cubic parts.

Changing methods with MAPAL

The responsible people at MTU decided to switch to a different machining method - face milling. “As we machine a 70 x 35 mm surface through a
rectangular opening only 54 mm wide, it was clear that we needed a special tool,” says Hans Schreiner. “We approached MAPAL with our problem,
because MAPAL has a reputation for mastering even difficult challenges. Other providers had already declined from the start.”

For MTU Friedrichshafen, MAPAL developed a 400 mm long milling cutter for finish machining. Its solid carbide shank has a diameter of 32 mm at the weakest point and is therefore significantly more stable than the shank of the counterboring tool. The face milling head is brazed onto it with four
tangentially arranged, adjustable ISO indexable inserts. The largest external dimension of the milling head is 63.5 mm. It fits through the 54 mm wide opening only at a defined spindle position. The indexable inserts with two cutting edges are set at an angle of 45°. They are arranged asymmetrically and have four different flight diameters: 19.5; 27.5; 44.5 and 54.5 mm. Despite a traverse path of only 10 mm, the entire surface with a length of 70 mm can be machined.

The arrangement of the inserts presented both the tool developers at MAPAL and our NC programmers with special challenges,” says Stefan Wohnhas. The Aalen-based precision tool specialists also had to use all their experience to ensure optimum axial run-out despite the complex asymmetry of the machining head. This was successful. Using an axial adjustment option, the axial run-out can be adjusted to the μm.

Working together for a special tool

The cooperation during the development phase was intensive. After each development step, MAPAL provided the MTU experts with a 3D model of the tool. “This ‘digital twin’ made it possible for us to simulate the entire machining cycle in our NC simulation software,” says Waldemar Schmidt, CAM Programming and Tool Planning at MTU Friedrichshafen. “This enabled us to detect collisions and fully test the behaviour of the milling cutter without having to produce expensive prototypes and without scrap.”

Conversely, MTU technicians made a significant contribution to the success of the project by making adjustments to the workpiece. In order to prevent the feared instability caused by a shank that is too thin, they made a minimal design modification at the entry opening.

Requirements clearly exceeded

“We were not always sure whether the design of a suitable milling tool would even succeed,” says Waldemar Schmidt. “MAPAL convinced us that the opposite was true. With the tool we clearly exceed the precision requirements,” reports Hans Schreiner. In this way, a flatness of seven instead of the required 70 μm is reliably achieved. 0.2 mm of material is removed during finishing. The average cutting speed is 120 m/min and the feed rate is 0.12 mm.

“Extensive measurements on a specially designed test engine confirmed the effect of fine machining with the special milling cutter developed by MAPAL,” adds Stefan Wohnhas: “We received a tool with which we were able to sustainably improve the low maintenance and long-term quality of our large engines by minimally invasive face milling with a long projection length.”


Rolls-Royce Power Systems, a division of the British technology group Rolls- Royce plc, is one of the world’s leading suppliers of engines, drive systems and decentralised energy systems. The MTU and MTU Onsite Energy brands focus on high-speed engines and drive systems for ships, heavy land and rail vehicles, military vehicles and for the oil and gas industry with up to 10,000 kW output, as well as for power generators for emergency, continuous and peak power supply and complete cogeneration plants.
