MAPAL Expert Day highlights potential in steel and cast machining

In the middle of May, the precision tool manufacturer MAPAL invited around 150 customers and interested parties to the “MAPAL Dialog” Expert Day at the company headquarters in Aalen. The two one-day events each focused on new developments in the machining of steel and cast materials. MAPAL’s very own core business, as Managing Partner Dr Jochen Kress emphasised in his introduction: “This is where our roots lie.” In order to break ground with new machining possibilities and more productivity for users, MAPAL is continuously and intensively working with these workpiece materials. Both in terms of tool geometry and high-performance coatings. “We have built up a lot of expertise,” emphasised Kress during his presentation. The company has its own coating facilities and a large analytical department for tools and workpiece materials. New opportunities will also be created thanks to the close cooperation between the research and development department and universities and scientific institutes.

An insight into one of these research projects was provided by Professor Dr Dirk Biermann, Head of the Institute for Machining Research at the Technical University of Dortmund. At the heart of the project was a central application, a part from a major car manufacturer. Biermann explained the optimum process strategy for spiral deep bore drilling with solid carbide tools and presented the influence of minimum quantity lubrication (MQL) on the temperature development during machining. What changes does the machining process do to the edges of the parts? And how can 3D printed tool holders be used for vibration dampening during turning? These questions were also part of the research, with results that were as astonishing as they were interesting.

Specialists from MAPAL highlighted the specific advantages provided by optimised tools when machining steel and cast materials. Ulrich Krenzer, Managing Director of the Centre of Competence for Solid Carbide Tools, demonstrated how a three-edged drill performs during cast and steel machining. It can machine an axial piston pump in half the time compared to a double edge tool. At the same time, it doubles the number of parts from 5,400 to 10,800.

Jochen Schmidt, Product Manager Clamping Technology, explained additive manufacturing and its advantages in hydraulic clamping technology. In order to achieve better cutting parameters and higher process reliability, the specialists use additive manufacturing to place the clamping range closer to the point of action and increase stability. “This has an enormous impact on the cost per part,” stressed Schmidt.

Markus Zapke, Team Leader for Tooling, Equipment & Processes at the Siemens gas turbine plant in Berlin, reported on the challenge of machining the blade groove of a large gas turbine. Siemens usually relies on reaming for this slot machining; a machining process for the production of inner and outer profiles. “In this case the slots were too deep, we would have had to buy a new machine,” said Zapke. As an alternative, MAPAL has developed custom tools for milling with which the slot can be machined smoothly.

Other presentations dealt with increasing tool life through high-performance coatings and new tools as well as methods for chip removal. Another topic that was discussed was the digitisation of production processes and the intelligent networking of machines.

Im Forschungs- und Entwicklungszentrum hatten die Teilnehmer die Gelegenheit, die Performance der Werkzeuge live auf der Bearbeitungsmaschine zu sehen. MAPAL präsentierte das Trochoide Fräsen sowie Hochleistungsbearbeitungen im Bereich Bohren und Fräsen. Ebenfalls im Fokus: ein neuer Spanbrecher für Stahl und das Fräserprogramm mit radialen ISO-Wendeschneidplatten für die Stahl- und Gussbearbeitung. Die Kunden und Interessierten nutzten die Gelegenheit, um sich bei den Entwicklungsingenieuren und Technikern zu informieren und vertiefende Gespräche zu führen.

Auch in den Pausen entstand ein lebhafter Austausch unter den Teilnehmern mit den Referenten, Produktspezialisten und Dr. Jochen Kress. Die begleitende Produktausstellung zeigte weitere Branchen und Einsatzfelder, in denen MAPAL tätig ist. Unter anderem den Werkzeug- und Formenbau, die digitale Werkzeuglogistik und den Bereich der E-Mobilität.
